Introduction

Hey guys, let's dive into a crucial topic for those of you pushing the limits of your APUs with ROCm: configuring TTM limits. For those unfamiliar, APUs often have a relatively small carve-out for VRAM, typically around 512MB. This limitation can impact performance, especially when dealing with memory-intensive tasks. The Linux kernel intelligently decides whether to utilize VRAM or GTT (Graphics Translation Table) based on their respective sizes. However, this default behavior might not always be optimal for everyone's specific use case. So, let's explore how we can tweak things to squeeze out the best possible performance.

To address these limitations, one potential avenue is adjusting the TTM (Translation Table Maps) page limit. The TTM page limit acts as a constraint on the amount of system memory that the graphics driver can utilize for graphics operations. By strategically increasing this limit, we can potentially enhance performance, especially in scenarios where the default VRAM allocation is insufficient. But before we jump into the how-to, let's understand why this matters and the challenges involved.

Many BIOSes offer options to increase the VRAM carve-out size or scale it dynamically with system RAM, providing a hardware-level solution. However, on Linux, there's another powerful trick up our sleeves: increasing the TTM page limit. This allows us to fine-tune how much system memory can be used for graphics, potentially boosting performance when the default VRAM allocation isn't enough. It’s important to note that this adjustment needs to be made before the TTM and AMDGPU drivers are loaded, adding a layer of complexity. The process involves modifying a kernel module parameter, which isn’t exactly user-friendly. Setting a 48GB limit, for instance, requires a calculation like this: int(48 * (1024*1024*1024) / 4096), resulting in the value 12582912. You'd then need to add this value as a module parameter to TTM, either via the kernel command line or in a module parameter configuration file within /etc/modprobe.d. This cumbersome process highlights the need for a more accessible solution. Manually calculating and configuring the TTM limit can be daunting, especially for users who aren't comfortable with command-line interfaces and system configuration files. The risk of misconfiguration is also present, potentially leading to system instability or performance degradation. Therefore, a user-friendly tool that simplifies this process would be a significant boon for the ROCm community.

The Challenge: A Not-So-User-Friendly Interface

The current method of adjusting the TTM limit involves directly manipulating a kernel module parameter, which isn't exactly a walk in the park. The unit is a bit obscure, and the process involves calculations that most users wouldn't want to deal with manually. For example, setting a 48GB limit requires a calculation like this:

> int(48 * (1024*1024*1024) / 4096)
12582912

You'd then need to take this value and add it as a module parameter to TTM, either on the kernel command line or in a module parameter configuration file in /etc/modprobe.d. This process leaves a lot to be desired in terms of user-friendliness. Imagine trying to explain this to a newcomer to Linux or ROCm! This complexity deters many users from optimizing their systems, leading to suboptimal performance. A more intuitive interface is crucial for democratizing access to these advanced configuration options.

A Solution: A User-Friendly Tool for TTM Configuration

To make this whole process smoother and more accessible, the suggestion is to integrate TTM limit configuration options into a user-facing tool like rocm-smi or amd-smi. This would provide a much more intuitive way for users to manage their TTM settings. Such a tool would greatly simplify the process of adjusting TTM limits, making it accessible to a broader range of users. By abstracting away the technical complexities, it empowers users to optimize their systems without needing to delve into the intricacies of kernel module parameters and configuration files. This would not only enhance the user experience but also encourage more users to explore and fine-tune their systems for optimal performance.

The idea is to add two key user-facing options:

  1. Read Current TTM Limit: This would allow users to easily check their current TTM limit by reading the /sys/module/ttm/parameters/pages_limit file. For example:

    ❯ cat /sys/module/ttm/parameters/pages_limit
3052026

  2. Write Updated TTM Limit: This is where the magic happens! The tool would handle the conversion and write the updated value to /etc/modprobe.d/rocm.conf. The input would be more user-friendly, allowing users to specify the limit in human-readable terms (e.g., --ttm-limit 48GB). The tool could even perform checks to prevent users from shooting themselves in the foot by setting the limit too high (e.g., warning if the limit exceeds 95% of system memory). After writing the configuration, the tool could call distro tools to rebuild the initramfs and prompt the user to reboot their system for the changes to take effect.

This approach would significantly simplify TTM configuration, making it accessible to a wider audience. The tool could validate user input, preventing accidental misconfigurations that could lead to system instability. By automating the process of rebuilding the initramfs and prompting for a reboot, the tool ensures that the changes are applied correctly and efficiently. This comprehensive solution would greatly improve the user experience and empower users to optimize their systems for peak performance.

Example Implementation

Let’s imagine how this user-friendly tool might work in practice. A user could simply type a command like rocm-smi --ttm-limit 48GB. The tool would then:

  1. Parse the input (48GB).
  2. Calculate the corresponding page limit value.
  3. Check the system memory to ensure the limit is reasonable (e.g., not exceeding 95% of available memory).
  4. Write the configuration to /etc/modprobe.d/rocm.conf.
  5. Rebuild the initramfs using the appropriate distro tools.
  6. Prompt the user to reboot.

This streamlined process eliminates the need for manual calculations and configuration file editing, making TTM limit adjustments a breeze. The built-in safety checks further enhance the user experience by preventing accidental misconfigurations. This example illustrates the potential of a user-friendly tool to transform a complex task into a simple, intuitive operation.

Benefits of a User-Friendly Tool

  • Simplified Configuration: No more manual calculations or editing configuration files!
  • Error Prevention: The tool can validate user input and prevent misconfigurations.
  • Improved User Experience: A more intuitive interface makes TTM configuration accessible to a wider audience.
  • Increased System Optimization: More users will be able to fine-tune their systems for optimal performance.

Use Case: Strix Halo and APU Optimization

This suggestion is particularly relevant for users with APUs like the upcoming Strix Halo. APUs often have limited VRAM, making TTM configuration crucial for maximizing performance. By providing a user-friendly way to adjust the TTM limit, we can empower users to get the most out of their hardware.

Conclusion

In conclusion, a user-friendly tool for configuring TTM limits would be a valuable addition to the ROCm ecosystem. It would simplify a complex process, prevent errors, and empower users to optimize their systems for peak performance. This is especially important for APU users who need to maximize their limited VRAM. Guys, let's make this happen! What do you think about this suggestion? Share your thoughts and ideas in the comments below!
